Home » WRS100SBR 1D Ring Barcode Scanner - 633809004018
WRS100SBR 1D Ring Barcode Scanner - 633809004018
WRS100SBR 1D Ring Barcode Scanner - 633809004018

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Wasp Barcode Technologies

WRS100SBR 1D Ring Barcode Scanner - 633809004018

1 in stock
SKU: 5390891
$212.98
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure

WRS100SBR 1D Ring Barcode Scanner

  • UPC: 633809004018
    • General Information
    • Manufacturer: Wasp Barcode Technologies
    • Manufacturer Part Number: 633809004018
    • Manufacturer Website Address: http://www.waspbarcode.com
    • Brand Name: Wasp
    • Product Model: WRS100SBR
    • Product Name: WRS100SBR 1D Ring Barcode Scanner
    • Product Type: Barcode Scanner
    Technical Information
    • Connectivity Technology: Cable/Wireless
    • Scanning Capability: 1D
    • Barcode Symbology Supported:
      • UPC-A/UPC-E
      • EAN-8/EAN-13
      • Industrial 2 of 5
      • Codabar
      • Matrix 2 of 5
      • Code 11
      • Code 93
      • Code 32
      • Code 128
      • Standard Code 39
      • Full ASCII Code 39
      • Interleaved 2 of 5
      • China Postal Code
      • MSI Plessy Code
      • UK Plessy Code
      • EAN/UCC 128
      • Telepen Code
      • IATA Code
      • GS1 Databar
    • Light Source: Laser
    • Image Sensor Type: Imager
    • Scan Rate: 400 scan/s
    • Scan Mode: Trigger
    • Scan Pattern: Linear
    • Scanning Distance: 10.04"
    • Cable Type Included: USB
    • Reading Angle (Skew): 40°
    • Reading Angle (Pitch): 30°
    • Reading Angle (Roll): 20°
    • Maximum Ambient Light: 70000 lux
    • Drop Specification:

      5 ft. (1.5 m)

    • Minimum Print Contrast: 30%
    • Minimum Element Resolution (Code 39): 4 mil
    • Maximum Element Resolution (Code 39): 15 mil
    • Air Electrostatic Discharge (+/-): 8kV
    • Contact Electrostatic Discharge (+/-): 4kV
    • Features:
      • Scan Button
      • Notification LED
      • Vibration
    Memory
    • Standard Memory: 2 MB
    Network & Communication
    • Bluetooth: Yes
    Interfaces/Ports
    • Host Interface: USB
    Battery Information
    • Battery Chemistry: Lithium Polymer (Li-Polymer)
    • Battery Capacity: 200 mAh
    Environmental Conditions
    • Operating Temperature: 14°F (-10°C) to 122°F (50°C)
    • Storage Temperature: -4°F (-20°C) to 140°F (60°C)
    • Humidity (Non-condensing): 0% to 95%
    Physical Characteristics
    • Form Factor: Wearable
    • Color Family: Dual Color
    • Product Color:
      • Yellow
      • Black
    • Product Material: ABS/PC
    • Durability: Drop Resistant
    • Height: 1.1"
    • Width: 1.1"
    • Length: 1.8"
    • Weight (Approximate): 0.72 oz
    Miscellaneous
    • Package Contents:
      • WRS100SBR Ring Barcode Scanner
      • USB charging cable
      • Velco strap
    • Ingress Protection (IP) Rating: IP42
    • Platform Supported:
      • iOS
      • Android
      • Windows
      • Smartphone
    • Country of Origin: Taiwan
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS) 2
      • Waste Electrical and Electronic Equipment Directive (WEEE)
      • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
