Home » Elo 1093L 10" Class Open-frame LCD Touchscreen Monitor - 16:10 - 25 ms - E321195
Elo 1093L 10" Class Open-frame LCD Touchscreen Monitor - 16:10 - 25 ms - E321195
Elo 1093L 10" Class Open-frame LCD Touchscreen Monitor - 16:10 - 25 ms - E321195

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Elo Touch Solutions, Inc

Elo 1093L 10" Class Open-frame LCD Touchscreen Monitor - 16:10 - 25 ms - E321195

1 in stock
SKU: 8887066
$475.80
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure
Click here for User Manual

Elo 1093L 10" Class Open-frame LCD Touchscreen Monitor - 16:10 - 25 ms

  • UPC: 815335025778
    • General Information
    • Manufacturer: Elo Touch Solutions, Inc
    • Manufacturer Part Number: E321195
    • Manufacturer Website Address: http://www.elotouch.com
    • Brand Name: Elo
    • Product Model: 1093L
    • Product Name: 1093L 10.1" Open Frame Touchscreen (RevB)
    • Packaged Quantity: 1
    • Product Type: Open-frame LCD Touchscreen Monitor
    Technical Information
    • Screen Size Class: 10"
    • Viewable Screen Size: 10.1"
    • Screen Mode: WXGA
    • Panel Technology: Thin Film Transistor (TFT)
    • Response Time: 25 ms
    • Aspect Ratio: 16:10
    • Horizontal Viewing Angle: 170°
    • Vertical Viewing Angle: 170°
    • Mount Type: Flush Mount
    • Backlight Technology: LED
    • Features: On-screen Display (OSD)
    • Horizontal Frequency: 30 kHz to 60 kHz
    • Vertical Frequency: 50 Hz to 75 Hz
    • Curved Screen: No
    Video
    • Maximum Resolution: 1280 x 800
    • Color Supported: 262,000 Colors
    • Contrast Ratio: 800:1
    • Brightness: 350 Nit
    Touchscreen Information
    • Touchscreen Type: TouchPro Projected Capacitive
    • Multi-touch Screen: Yes
    • Number of Simultaneous Touchpoints: 10
    Interfaces/Ports
    • HDMI: Yes
    • USB: Yes
    • VGA: Yes
    • DisplayPort: Yes
    Power Description
    • Operating Power Consumption: 25 W
    • Standby Power Consumption: 700 mW
    • Off-Mode Power Consumption: 500 mW
    Physical Characteristics
    • Color Family: Black
    • Product Color: Black
    • VESA Mount Compatible: Yes
    • VESA Mount Standard: 75 x 75
    • Height: 7"
    • Width: 10.1"
    • Depth: 1.5"
    • Weight (Approximate): 2.65 lb
    Miscellaneous
    • Package Contents:
      • 1093L 10.1" Open Frame Touchscreen (RevB)
      • HDMI Cable
      • VGA Cable
      • RJ45 OSD Remote
      • Touch USB Cable
      • User Manual CD
      • Quick Install Guide
      • EEI Label
      • Japan Class-B TM info sheet
    • TAA Compliant: No
    • Environmentally Friendly: Yes
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • China Restriction of Hazardous Substances (China RoHS)
      • Waste Electrical and Electronic Equipment Directive (WEEE)
    Warranty
    • Limited Warranty: 3 Year
