Panduit EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS - E36D28L
Panduit EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS - E36D28L

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

PANDUIT CORP

Panduit EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS - E36D28L

1 in stock
SKU: 14906559
$2,139.79
-11% $2,392.31 $2,139.79
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Additional pdf1
Click here for Manufacturer Brochure
Click here for User Manual

Panduit EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS

  • UPC: 613056901964
    • General Information
    • Manufacturer: PANDUIT CORP
    • Manufacturer Part Number: E36D28L
    • Manufacturer Website Address: http://www.panduit.com
    • Brand Name: Panduit
    • Product Name: EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS
    • Packaged Quantity: 1 Piece
    • Product Type: PDU
    Technical Information
    • PDU Type: Monitored
    • Phase: Three Phase
    • Plug/Connector Type: NEMA L21-30P
    • Receptacle Type:
      • IEC 60320 C13/C15
      • IEC 60320 C13/C15/C19/C21
    • Receptacle Detail:
      • 18 x IEC 60320 C13/C15
      • 18 x IEC 60320 C13/C15/C19/C21
    • Features:
      • Onboard Display
      • SNMP Compatible
    Power Description
    • Output Voltage: 208 V AC
    • Power Rating (VA): 8600 VA
    • Input Current: 30 A
    Physical Characteristics
    • Color Family: Black
    • Product Color: Black
    • Product Material: Metal
    • Mounting Orientation: Vertical
    • Mount Type: Rack-mountable
    • Rack Height: 0U
    • Cord Length: 9.84 ft
    • Height: 70"
    • Width: 2"
    • Depth: 3"
    Environmental Conditions
    • Minimum Operating Temperature: 50°F (10°C)
    • Maximum Operating Temperature: 140°F (60°C)
    • Minimum Storage Temperature: -4°F (-20°C)
    • Maximum Storage Temperature: 140°F (60°C)
    Miscellaneous
    • Package Contents:
      • EL2P MI PDU, 30 AMP, 3 PH , 36 OUTLETS
      • Mounting Hardware
    • Country of Origin: Taiwan
    • Environmentally Friendly: Yes
    • Environmental Certification:
      • RoHS
      • REACH
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    Warranty
    • Limited Warranty: 5 Year
