Elo 1903LM 19" Class LCD Touchscreen Monitor - 5:4 - 14 ms - E658394
Elo 1903LM 19" Class LCD Touchscreen Monitor - 5:4 - 14 ms - E658394

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Elo Touch Solutions, Inc

Elo 1903LM 19" Class LCD Touchscreen Monitor - 5:4 - 14 ms - E658394

1 in stock
SKU: 7829365
$1,102.45
-2% $1,127.00 $1,102.45
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure
Click here for User Manual

Elo 1903LM 19" Class LCD Touchscreen Monitor - 5:4 - 14 ms

  • UPC: 843173135427
    • General Information
    • Manufacturer: Elo Touch Solutions, Inc
    • Manufacturer Part Number: E658394
    • Manufacturer Website Address: http://www.elotouch.com
    • Brand Name: Elo
    • Product Series: 03
    • Product Model: 1903LM
    • Product Name: 1903LM 19" Medical Grade Touchscreen Monitor
    • Product Type: LCD Touchscreen Monitor
    Technical Information
    • Screen Size Class: 19"
    • Viewable Screen Size: 19"
    • Screen Mode: SXGA
    • Response Time: 14 ms
    • Aspect Ratio: 5:4
    • Horizontal Viewing Angle: 178°
    • Vertical Viewing Angle: 178°
    • Mount Type: Desk Mountable
    • Backlight Technology: LED
    • Features:
      • Anti-glare
      • On-screen Display (OSD)
    • Horizontal Frequency: 30 kHz to 82 kHz
    • Vertical Frequency: 50 Hz to 75 Hz
    Video
    • Maximum Resolution: 1280 x 1024
    • Color Supported: 16.7 Million Colors
    • Native Contrast Ratio: 1,000:1
    • Brightness: 225 Nit
    Audio
    • Speakers: Yes
    Touchscreen Information
    • Touchscreen Type: Projected Capacitive
    • Multi-touch Screen: Yes
    • Number of Simultaneous Touchpoints: 10
    Interfaces/Ports
    • HDMI: Yes
    • USB: Yes
    • Number of USB Ports: 4
    Built-in Devices
    • Built-in Devices: USB Hub
    Power Description
    • Operating Power Consumption: 16.36 W
    Physical Characteristics
    • Color Family: Black
    • Product Color: Black
    • VESA Mount Compatible: Yes
    • VESA Mount Standard: 100 x 100
    • Height with Stand: 15.66"
    • Width with Stand: 16.91"
    • Depth with Stand: 7.61"
    • Weight (Approximate): 9.48 lb
    • Weight with Stand (Approximate): 13.90 lb
    Miscellaneous
    • Package Contents:
      • 1903LM 19" Medical Grade Touchscreen Monitor
      • Quick Install Guide
      • 3 x Tie wraps
      • VGA cable
      • HDMI cable
      • Touch USB cable
      • Audio cable
      • Power brick
      • NA Power cable
      • EU Power cable
      • EEI Label
      • DICOM calibration sheet
    • Country of Origin: China
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • China Restriction of Hazardous Substances (China RoHS)
      • Waste Electrical and Electronic Equipment Directive (WEEE)
      • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    Warranty
    • Limited Warranty: 3 Year
