Minuteman 1500 VA On-line Tower UPS with 6 0utlets - EC1500LCD
Regular price
$989.68
Regular price
-29%
$1,400.00
Sale price
$989.68
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Couldn't load pickup availability
Click here for Manufacturer Brochure
Click here for User Manual
UPC: 784755155382
General Information
Click here for User Manual
Minuteman 1500 VA On-line Tower UPS with 6 0utlets
- Manufacturer: Para Systems, Inc
- Manufacturer Part Number: EC1500LCD
- Manufacturer Website Address: http://www.minutemanups.com
- Brand Name: Minuteman
- Product Line: Encompass
- Product Model: EC1500LCD
- Product Name: 1500 VA On-line Tower UPS with 6 0utlets
- Product Type: Double Conversion Online UPS
- Plug/Connector Type: NEMA 5-15P
- Receptacle Type: NEMA 5-15R
- Receptacle Detail: 6 x NEMA 5-15R
- Dataline Protection:
- RJ-45
- RJ-11
- Transfer Time: 0 ns
- EMI/RFI Noise Filter: Yes
- Application/Usage:
- Voice/Data Network
- Server
- Electronic Device
- Medical
- Healthcare
- Lab Equipment
- Security System
- Education
- Network
- Load Capacity (VA): 1500 VA
- Load Capacity (Watt): 1350 W
- Input Voltage: 120 V AC
- Input Voltage Range: 0 V AC - 160 V AC
- Output Voltage:
- 110 V AC
- 120 V AC
- 127 V AC
- Input Frequency: 60 Hz
- Output Frequency: 60 Hz
- Waveform Type: Pure Sine Wave
- Surge Energy Rating: 254 J
- Network Management: SNMP Manageable
- Status Indicators:
- LCD Status Panel
- Alarm
- Serial Port: Yes
- EPO Port: Yes
- USB (HID Compliant) Port: Yes
- Number of Batteries: 1
- Battery Characteristics: Sealed, Non-spillable, Maintenance-free
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 5 Minute
- Backup/Run Time (Half Load): 15 Minute
- Hot Swappable: Yes
- Replaceable Battery: Yes
- Maximum Operating Elevation: 10000 ft
- Maximum Storage Elevation: 50000 ft
- Storage Temperature: 14°F (-10°C) - 122°F (50°C)
- Operating Humidity: 10% - 90%
- Storage Relative Humidity: 10% - 90%
- Maximum Operating Temperature: 104°F (40°C)
- Sound Emission (A-Weighted): 55 dB(A)
- Height: 11.4"
- Width: 6.8"
- Depth: 17.4"
- Form Factor: Tower
- Weight (Approximate): 48.10 lb
- Package Contents:
- 1500 VA On-line Tower UPS with 6 0utlets
- Batteries Disconnected
- Quick Installation Guide
- Software Included: Minuteman SentryHD Power Monitoring and Control Software
- Environmentally Friendly: Yes
- Limited Warranty: 3 Year
