Vertiv Edge UPS 2200VA 1980W 230V 2U Line Interactive AVR Tower/Rack Mount - EDGE-2200IRT2UXL
Vertiv Edge UPS 2200VA 1980W 230V 2U Line Interactive AVR Tower/Rack Mount - EDGE-2200IRT2UXL

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Vertiv

Vertiv Edge UPS 2200VA 1980W 230V 2U Line Interactive AVR Tower/Rack Mount - EDGE-2200IRT2UXL

4 in stock
SKU: 12517521
$1,380.60
-29% $1,944.00 $1,380.60
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Click here for Manufacturer Brochure

Vertiv Edge UPS 2200VA 1980W 230V 2U Line Interactive AVR Tower/Rack Mount

  • UPC : N/A
    • General Information
    • Manufacturer: Vertiv
    • Manufacturer Part Number: EDGE-2200IRT2UXL
    • Manufacturer Website Address: http://www.vertiv.com/
    • Brand Name: VERTIV
    • Product Line: EDGE
    • Product Model: EDGE-2200IRT2UXL
    • Product Name: EDGE EDGE-2200IRT2UXL 2200VA Tower UPS
    • Product Type: Line-interactive UPS
    Technical Information
    • Receptacle Type:
      • IEC 60320 C13
      • IEC 60320 C19
    • Receptacle Detail:
      • 6 x IEC 60320 C13
      • 1 x IEC 60320 C19
    • Transfer Time: 4 ms
    • Phase: Single Phase
    Power Description
    • Load Capacity (VA): 2200 VA
    • Load Capacity (Watt): 1980 W
    • Input Voltage Range: 144 V AC - 290 V AC
    • Output Voltage:
      • 200 V AC
      • 208 V AC
      • 220 V AC
      • 230 V AC
      • 240 V AC
    • Input Frequency: 65 Hz
    • Waveform Type: Pure Sine Wave
    • Circuit Breaker: Yes
    Management
    • Alarm: Yes
    Controls/Indicators
    • Status Indicators:

      LCD Display

    Interfaces/Ports
    • USB: Yes
    • USB (HID Compliant) Port: Yes
    Battery Information
    • DC System Voltage: 72 V DC
    • Number of Batteries: 6
    • Battery Characteristics: Valve-regulated, Non-spillable
    • Battery Chemistry: Lead Acid
    • Battery Size: 12V
    • Battery Capacity: 7000 mAh
    • Backup/Run Time (Full Load): 4.40 Minute
    • Backup/Run Time (Half Load): 14 Minute
    • Hot Swappable: Yes
    • Typical Battery Recharge Time: 3 Hour
    Environmental Conditions
    • Storage Temperature: -13°F (-25°C) - 131°F (55°C)
    • Maximum Operating Temperature: 104°F (40°C)
    • Sound Emission: 45 dB
    Physical Characteristics
    • Product Color: Black
    • Height: 3.5"
    • Width: 17.2"
    • Depth: 24.8"
    • Rack Height: 2U
    • Form Factor: Rack/Tower
    • Weight (Approximate): 59.52 lb
    Miscellaneous
    • Energy Star: No
    • TAA Compliant: No
