Datalogic Gryphon I GD4520 Barcode Scanner Kit - GD4520-BKK1-HD
Datalogic Gryphon I GD4520 Barcode Scanner Kit - GD4520-BKK1-HD

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Datalogic S.p.A

Datalogic Gryphon I GD4520 Barcode Scanner Kit - GD4520-BKK1-HD

19 in stock
SKU: 7657488
$448.21
-13% $515.00 $448.21
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure
Click here for Video

Datalogic Gryphon I GD4520 Barcode Scanner Kit

  • UPC : N/A
    • General Information
    • Manufacturer: Datalogic S.p.A
    • Manufacturer Part Number: GD4520BKK1HD
    • Manufacturer Website Address: http://www.datalogic.com
    • Brand Name: Datalogic
    • Product Line: Gryphon I
    • Product Series: GD4500
    • Product Model: GD4520
    • Product Name: Gryphon I GD4520 Barcode Scanner Kit
    • Product Type: Barcode Scanner Kit
    Technical Information
    • Connectivity Technology: Cable
    • Scanning Capability:
      • 1D
      • 2D
    • Barcode Symbology Supported:

      1D:

      • Auto discriminates all standard 1D codes including GS1 DataBar linear codes.

      2D:

      • Aztec Code
      • China Han Xin Code
      • Data Matrix
      • MaxiCode
      • Micro QR Code
      • QR Code
      • Dot Code

      Postal Codes:

      • Australian Post
      • British Post
      • China Post
      • IMB
      • Japanese Post
      • KIX Post
      • Planet Code
      • Postnet
      • Royal Mail Code (RM4SCC)

      Stacked Codes:

      • EAN/JAN Composites
      • GS1 DataBar Composites
      • GS1 DataBar Expanded Stacked
      • GS1 DataBar Stacked
      • GS1 DataBar Stacked Omnidirectional
      • MacroPDF
      • MicroPDF417
      • PDF417
      • UPC A/E Composites

      Digital Watermarking:

      • Digimarc Barcodes
    • Light Source: Laser
    • Image Sensor Type: Imager
    • Scan Pattern: Omni-directional
    • Scanner Range: High Density
    • Scanning Distance: 15.70"
    • Cable Type Included: USB
    • Reading Angle (Skew): 65°
    • Reading Angle (Pitch): 65°
    • Reading Angle (Roll): 360°
    • Motion Tolerance: 35 in/s
    • Image Formats:
      • BMP
      • TIFF
      • JPEG
    • Maximum Ambient Light: 100000 lux
    • Drop Specification:

      Withstands repeated drops from 1.8 m / 6.0 ft onto a concrete surface.

    • Minimum Print Contrast: 15%
    • Minimum Element Resolution (Code 39): 3 mil
    • Maximum Element Resolution (Code 39): 5 mil
    • Minimum Element Resolution (DataMatrix): 5 mil
    • Maximum Element Resolution (DataMatrix): 10 mil
    • Minimum Element Resolution (PDF417): 4 mil
    • Maximum Element Resolution (PDF417): 10 mil
    • Image Sensor Resolution: 1280 x 800
    • Illumination Type: LED
    • Illumination Color: White
    • Air Electrostatic Discharge (+/-): 16kV
    • Features:
      • Grayscale Image Capture
      • Beep
      • 3GL
      • Notification LED
      • Ergonomic Design
    Interfaces/Ports
    • Host Interface: USB
    Environmental Conditions
    • Operating Temperature: 32°F (0°C) to 122°F (50°C)
    • Storage Temperature: -40°F (-40°C) to 158°F (70°C)
    • Humidity (Non-condensing): 0% to 95%
    Physical Characteristics
    • Form Factor: Handheld
    • Color Family: Black
    • Product Color: Black
    • Durability: Drop Resistant
    • Weight (Approximate): 5.68 oz
    Miscellaneous
    • Ingress Protection (IP) Rating: IP52
    • Application/Usage:
      • Healthcare
      • Retail
      • Light/Clean Manufacturing
      • Transportation
      • Commercial Service
      • Laboratory
      • Pharmacy
