Home » APC Smart-UPS, Line Interactive, 500VA, Lithium-ion, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port, Short Depth - SCL500RM1UC
APC Smart-UPS, Line Interactive, 500VA, Lithium-ion, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port, Short Depth - SCL500RM1UC
APC Smart-UPS, Line Interactive, 500VA, Lithium-ion, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port, Short Depth - SCL500RM1UC

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Schneider Electric SA

APC Smart-UPS, Line Interactive, 500VA, Lithium-ion, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port, Short Depth - SCL500RM1UC

1063 in stock
SKU: 5602777
$441.11
-33% $657.00 $441.11
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Click here for Additional pdf1
Click here for Additional pdf10
Click here for Additional pdf2
Click here for Additional pdf3
Click here for Additional pdf4
Click here for Additional pdf5
Click here for Additional pdf6
Click here for Additional pdf7
Click here for Additional pdf8
Click here for Additional pdf9
Click here for Manufacturer Brochure
Click here for User Manual

APC Smart-UPS, Line Interactive, 500VA, Lithium-ion, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port, Short Depth

  • UPC: 731304344551
    • General Information
    • Manufacturer: Schneider Electric SA
    • Manufacturer Part Number: SCL500RM1UC
    • Manufacturer Website Address: http://www.schneider-electric.com
    • Brand Name: APC by Schneider Electric
    • Product Line: Smart-UPS
    • Product Name: Smart-UPS 500VA Rack/Floor Mountable UPS
    • Packaged Quantity: 1 Each
    • Product Type: Line-interactive UPS
    Technical Information
    • AVR: Yes
    • Plug/Connector Type: NEMA 5-15P
    • Receptacle Type: NEMA 5-15P
    • Receptacle Detail: 4 x NEMA 5-15R
    • Number of Battery & Surge Outlets: 4
    • Dataline Protection: RJ-45
    • Cord Length: 6 ft
    • Transfer Time: 10 ms
    • Application/Usage:
      • Network
      • Server
      • POS Terminal
      • Router
      • Switch
      • Network Hub
      • Equipment
      • Business
      • Storage
      • Security System
      • Communication System
      • Voice/Data Network
    Power Description
    • Load Capacity (VA): 500 VA
    • Load Capacity (Watt): 400 W
    • Input Voltage: 120 V
    • Input Voltage Range: 92 V AC - 139 V AC
    • Output Voltage: 120 V AC
    • Input Frequency: 63 Hz
    • Output Frequency: 60 Hz
    • Waveform Type: Sine Wave
    • Surge Energy Rating: 680 J
    Management
    • Network Management: SmartConnect
    • Alarm:
      • On Battery
      • Low Battery
      • Configurable Delay
    Controls/Indicators
    • Status Indicators: LED Display
    Interfaces/Ports
    • Serial Port: Yes
    • Network (RJ-45): Yes
    • EPO Port: Yes
    • USB (HID Compliant) Port: Yes
    Battery Information
    • Battery Characteristics: Valve-regulated
    • Battery Chemistry: Lithium Ion (Li-Ion)
    • Backup/Run Time (Full Load): 2.70 Minute
    • Backup/Run Time (Half Load): 6.30 Minute
    • Hot Swappable: Yes
    • Typical Battery Recharge Time: 3 Hour
    • Replaceable Battery: Yes
    Environmental Conditions
    • Maximum Operating Elevation: 6561 ft
    • Maximum Storage Elevation: 49212 ft
    • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
    • Operating Humidity: 10% - 90%
    • Storage Relative Humidity: 10% - 90%
    • Maximum Operating Temperature: 104°F (40°C)
    • Sound Emission (A-Weighted): 45 dB(A)
    Physical Characteristics
    • Product Color:
      • Black
      • Silver
    • Height: 1.7"
    • Width: 17"
    • Depth: 9.1"
    • Rack Height: 1U
    • Form Factor: Rack-mountable
    • Weight (Approximate): 9.22 lb
    Miscellaneous
    • Package Contents:
    • Smart-UPS 500VA Rack/Floor Mountable UPS
    • CD with software
    • Documentation CD
    • Installation guide
    • Rack mounting support rails
    • USB cable
    • Software Included: Powerchute Serial Edition
    • Energy Star: Yes
    • Country of Origin: Philippines
    • Environmentally Friendly: Yes
    • Environmental Compliance: Restriction of Hazardous Substances (RoHS)
    Warranty
    • Limited Warranty: 5 Year
    • Additional Warranty Information: 5 year repair or replace
