Home » Eaton Tripp Lite Series 750VA 600W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, RS-232, LCD, Tower - SMART750TSU
Eaton Tripp Lite Series 750VA 600W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, RS-232, LCD, Tower - SMART750TSU
Eaton Tripp Lite Series 750VA 600W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, RS-232, LCD, Tower - SMART750TSU

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Eaton Corporation

Eaton Tripp Lite Series 750VA 600W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, RS-232, LCD, Tower - SMART750TSU

48 in stock
SKU: 5644081
$343.12
-32% $502.00 $343.12
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure
Click here for User Manual

Eaton Tripp Lite Series 750VA 600W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, RS-232, LCD, Tower

  • UPC: 037332214225
    • General Information
    • Manufacturer: Eaton Corporation
    • Manufacturer Part Number: SMART750TSU
    • Manufacturer Website Address: http://www.eaton.com
    • Brand Name: Tripp Lite series
    • Product Line: SmartPro
    • Product Model: SMART750TSU
    • Product Name: SMART750TSU 750VA Tower UPS
    • Product Type: Line-interactive UPS
    Technical Information
    • AVR: Yes
    • Plug/Connector Type: NEMA 5-15P
    • Receptacle Type: NEMA 5-15R
    • Receptacle Detail: 8 x NEMA 5-15R
    • Number of Battery & Surge Outlets: 6
    • Number of Surge-only Outlets: 2
    • Transfer Time: 6 ms
    • EMI/RFI Noise Filter: Yes
    • Phase: Single Phase
    • Energy Saving: Greater than 95% efficiency - GREEN UPS
    • Application/Usage:
      • Network
      • Digital Signage
      • Security System
      • Monitor
      • Desktop Computer
      • Retail and Wholesale
      • Casino
      • High-end System Component
      • DVR
      • Wireless Router
      • Home Network
      • Speaker
      • Printer
      • Home Theater
      • Workstation
      • Equipment
    Power Description
    • Load Capacity (VA): 750 VA
    • Load Capacity (Watt): 600 W
    • Input Voltage: 120 V AC
    • Output Voltage:
      • 120 V AC
      • 115 V AC
      • 110 V AC
    • Input Frequency: 60 Hz
    • Output Frequency: 60 Hz
    • Waveform Type: Pulse-width Modulated Sine Wave
    • Surge Energy Rating: 316 J
    Management
    • Alarm:
      • Low Battery
      • Fault
      • Overload
      • Replace Battery
    Controls/Indicators
    • Status Indicators:

      Front Panel LCD Display:

      • Input voltage
      • Output voltage
      • Load percentage
      • Battery charge percentage
      • Overload status
    Interfaces/Ports
    • Serial Port: Yes
    • USB (HID Compliant) Port: Yes
    Battery Information
    • DC System Voltage: 12 V DC
    • Backup/Run Time (Full Load): 4 Minute
    • Backup/Run Time (Half Load): 13 Minute
    • Typical Battery Recharge Time: 8 Hour
    • Replaceable Battery: Yes
    Environmental Conditions
    • Maximum Operating Elevation: 9842.52 ft
    • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
    • Maximum Operating Temperature: 104°F (40°C)
    • Thermal Dissipation: 42.50 W
    Physical Characteristics
    • Height: 7.5"
    • Width: 5.5"
    • Depth: 15"
    • Form Factor: Tower
    • Weight (Approximate): 23.10 lb
    Miscellaneous
    • Package Contents:
      • SMART750TSU 750VA Tower UPS
      • USB Cable
      • DB9 Cable
      • Owner's Manual
    • Country of Origin: Vietnam
    • Environmentally Friendly: Yes
    • Environmental Compliance: Restriction of Hazardous Substances (RoHS)
    Warranty
    • Limited Warranty: 3 Year
