Home » APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, AVR, LCD - SMT1500RM1UC
APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, AVR, LCD - SMT1500RM1UC
APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, AVR, LCD - SMT1500RM1UC

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Schneider Electric SA

APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, AVR, LCD - SMT1500RM1UC

97 in stock
SKU: 6841101
$2,589.17
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Additional pdf1
Click here for Additional pdf2
Click here for Additional pdf3
Click here for Additional pdf4
Click here for Additional pdf5
Click here for Manufacturer Brochure
Click here for User Manual

APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, AVR, LCD

  • UPC: 731304426240
    • General Information
    • Manufacturer: Schneider Electric SA
    • Manufacturer Part Number: SMT1500RM1UC
    • Manufacturer Website Address: http://www.schneider-electric.com
    • Brand Name: APC by Schneider Electric
    • Product Line: Smart-UPS
    • Product Series: SMT
    • Product Name: Smart-UPS SMT 1500VA Rack-mountable UPS
    • Packaged Quantity: 1
    • Product Type: Line-interactive UPS
    Technical Information
    • AVR: Yes
    • Plug/Connector Type: NEMA 5-15P
    • Receptacle Type: NEMA 5-15P
    • Receptacle Detail: 4 x NEMA 5-15R
    • Cord Length: 8 ft
    • Transfer Time: 4 ms
    • Application/Usage:
      • IT
      • Network Device
      • Business
      • Critical System
      • Electronic
      • Server
      • POS
      • Router
      • Switch
      • Hub
      • VoIP
      • Network Closet
      • Storage
      • Edge Computing
      • Healthcare
      • Education
      • Retail
    Power Description
    • Load Capacity (VA): 1440 VA
    • Load Capacity (Watt): 1000 W
    • Input Voltage: 120 V
    • Input Voltage Range:
      • 93.5 V AC - 143 V AC
      • 85 V AC - 155 V AC
    • Input Current: 12 A
    • Output Voltage: 120 V AC
    • Input Frequency: 60 Hz
    • Output Frequency: 60 Hz
    • Waveform Type: Sine Wave
    • Surge Energy Rating: 645 J
    • Input Power Factor: 0.7
    Display & Graphics
    • Display: LCD
    Management
    • Network Management: SmartConnect
    • Alarm:
      • On Battery
      • Low Battery
      • Configurable Delay
    Controls/Indicators
    • Status Indicators:

      Multi-function LCD status and control console

    Interfaces/Ports
    • Serial Port: Yes
    • USB: Yes
    • Network (RJ-45): Yes
    • EPO Port: Yes
    Battery Information
    • Battery Chemistry: Lead Acid
    • Battery Size: 36V
    • Battery Capacity: 54000 mAh
    • Battery Energy: 1054.8 kJ
    • Backup/Run Time (Full Load): 4.75 Minute
    • Backup/Run Time (Half Load): 16.57 Minute
    • Battery Life: 5 Year
    • Typical Battery Recharge Time: 4 Hour
    • Replaceable Battery: Yes
    Environmental Conditions
    • Maximum Operating Elevation: 10000 ft
    • Maximum Storage Elevation: 50000 ft
    • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
    • Storage Relative Humidity: 0% - 95%
    • Maximum Operating Temperature: 104°F (40°C)
    • Sound Emission: 46 dB
    • Thermal Dissipation: 34 W
    Physical Characteristics
    • Product Color: Black
    • Height: 1.7"
    • Width: 17"
    • Depth: 26.2"
    • Rack Height: 1U
    • Form Factor: Rack-mountable
    • Weight (Approximate): 54.01 lb
    Miscellaneous
    • Package Contents:
      • Smart-UPS SMT 1500VA Rack-mountable UPS
      • Installation Guide
      • Rack Mounting Support Rails
      • Smart UPS Signalling RS-232 Cable
      • USB Cable
      • Safety Guide
      • 2 x IEC Jumper Cable
    • Software Included: Powerchute Serial Edition
    • Energy Star: Yes
    • Country of Origin: Philippines
    • Environmentally Friendly: Yes
    • Energy Efficiency Certification: ENERGY STAR 2.0
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • Waste Electrical and Electronic Equipment Directive (WEEE)
    Warranty
    • Limited Warranty: 3 Year
    • Additional Warranty Information: 3 years repair or replace (excluding battery) and 2 years for battery
