Home » APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord - SMX2KR2UNCX145
APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord - SMX2KR2UNCX145
APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord - SMX2KR2UNCX145

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Schneider Electric SA

APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord - SMX2KR2UNCX145

1 in stock
SKU: 5688390
$2,320.34
-33% $3,460.00 $2,320.34
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Additional pdf1
Click here for Additional pdf2
Click here for Additional pdf3
Click here for Additional pdf4
Click here for Additional pdf5
Click here for User Manual

APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord

  • UPC: 731304343271
    • General Information
    • Manufacturer: Schneider Electric SA
    • Manufacturer Part Number: SMX2KR2UNCX145
    • Manufacturer Website Address: http://www.schneider-electric.com
    • Brand Name: APC by Schneider Electric
    • Product Line: Smart-UPS
    • Product Series: X
    • Product Name: Smart-UPS X 1920VA Rack/Tower UPS
    • Product Type: Line-interactive UPS
    Technical Information
    • AVR: Yes
    • Plug/Connector Type: NEMA L5-20P
    • Receptacle Type: NEMA L5-20P
    • Receptacle Detail:
      • 1 x NEMA L5-20R
      • 3 x NEMA 5-15R
      • 3 x NEMA 5-20R
    • Number of Battery & Surge Outlets: 7
    • Cord Length: 10 ft
    • Transfer Time: 4 ms
    • Phase: Single Phase
    • Application/Usage:
      • Server
      • POS Terminal
      • Router
      • Switch
      • Network Hub
      • Critical System
      • Storage Device
      • Network Device
      • Business
      • Security System
      • Communication System
      • IT Equipment
    Power Description
    • Load Capacity (VA): 1920 VA
    • Load Capacity (Watt): 1800 W
    • Input Voltage: 120 V AC
    • Input Voltage Range: 70 V AC - 153 V AC
    • Output Voltage: 120 V AC
    • Input Frequency: 60 Hz
    • Output Frequency: 60 Hz
    • Waveform Type: Sine Wave
    • Surge Energy Rating: 540 J
    Management
    • Network Management: USB
    • Alarm:
      • On Battery
      • Low Battery
      • Overload
      • Configurable Delay
      • Changing Utility Power
      • UPS Power Condition
    Controls/Indicators
    • Status Indicators:

      LED Status Indicators:

      • Unit Status
      • Power Status
      • On Line
      • On Battery
      • Replace Battery
      • Overload
    Interfaces/Ports
    • Serial Port: Yes
    • Network (RJ-45): Yes
    • USB (HID Compliant) Port: Yes
    Battery Information
    • Number of Batteries: 1
    • Battery Characteristics: Maintenance-free, Sealed, Leak-proof
    • Battery Chemistry: Lead Acid
    • Battery Energy: 2484 kJ
    • Backup/Run Time (Full Load): 10.90 Minute
    • Backup/Run Time (Half Load): 27.60 Minute
    • Hot Swappable: Yes
    • Typical Battery Recharge Time: 3 Hour
    • Replaceable Battery: Yes
    Environmental Conditions
    • Maximum Operating Elevation: 9842.52 ft
    • Maximum Storage Elevation: 49212.60 ft
    • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
    • Storage Relative Humidity: 0% - 95%
    • Maximum Operating Temperature: 104°F (40°C)
    • Sound Emission (A-Weighted): 55 dB(A)
    • Thermal Dissipation: 59.49 W
    Physical Characteristics
    • Product Color: Black
    • Height: 3.3"
    • Width: 17"
    • Depth: 26.3"
    • Rack Height: 2U
    • Form Factor: Rack-mountable
    • Weight (Approximate): 84.77 lb
    Miscellaneous
    • Package Contents:
    • Smart-UPS X 1920VA Rack/Tower UPS
    • CD with software
    • Documentation CD
    • Installation guide
    • Network management card
    • Rack mounting brackets
    • Rack mounting hardware
    • Rack mounting support rails
    • Smart UPS signalling RS-232 cable
    • USB cable
    • Software Included: Powerchute® Business Edition Software
    • Country of Origin: Philippines
    • Environmentally Friendly: Yes
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
      • Battery Directive
    Warranty
    • Limited Warranty: 3 Year
    • Additional Warranty Information: UPS: 36 month(s)|Battery: 24 month(s)
