Panduit SmartZone U05N11V 5000VA Rack/Tower UPS - U05N11V
Panduit SmartZone U05N11V 5000VA Rack/Tower UPS - U05N11V

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

PANDUIT CORP

Panduit SmartZone U05N11V 5000VA Rack/Tower UPS - U05N11V

1 in stock
SKU: 12737789
$4,898.18
-11% $5,476.22 $4,898.18
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Additional pdf1
Click here for Manufacturer Brochure
Click here for User Manual

Panduit SmartZone U05N11V 5000VA Rack/Tower UPS

  • UPC: 613056825277
    • General Information
    • Manufacturer: PANDUIT CORP
    • Manufacturer Part Number: U05N11V
    • Manufacturer Website Address: http://www.panduit.com
    • Brand Name: Panduit
    • Product Line: SmartZone
    • Product Model: U05N11V
    • Product Name: SmartZone U05N11V 5000VA Rack/Tower UPS
    • Product Type: Double Conversion Online UPS
    Technical Information
    • AVR: Yes
    • Plug/Connector Type: NEMA L6-30R
    • Receptacle Type: NEMA L6-30R
    • Receptacle Detail: 4 x NEMA L6-30R
    • Dataline Protection: RJ-45
    • Overload Protection: Yes
    • Transfer Time: 0 ns
    • Phase: Single Phase
    • Application/Usage:
      • Data Center
      • IT Equipment
      • Computer
      • Edge Computing
    Power Description
    • Load Capacity (VA): 5000 VA
    • Load Capacity (Watt): 5000 W
    • Input Voltage:
      • 120 V AC
      • 230 V AC
    • Input Voltage Range:
      • 185 V AC - 264 V AC
      • 110 V AC - 285 V AC
    • Output Voltage:
      • 208 V AC
      • 240 V AC
    • Input Frequency: 70 Hz
    • Output Frequency: 60 Hz
    • Waveform Type: Pure Sine Wave
    • Surge Energy Rating: 600 J
    Management
    • Alarm: Yes
    Controls/Indicators
    • Status Indicators: Colorful LCD with four buttons and LED indicators
    Interfaces/Ports
    • Serial Port: Yes
    • Network (RJ-45): Yes
    • EPO Port: Yes
    • USB (HID Compliant) Port: Yes
    Battery Information
    • DC System Voltage: 240 V DC
    • Number of Batteries: 20
    • Battery Characteristics: Valve-regulated, Maintenance-free, Hot-swappable
    • Battery Chemistry: Sealed Lead Acid (VRLA)
    • Battery Size: 12V
    • Battery Capacity: 9000 mAh
    • Backup/Run Time With External Battery Cabinet (Full Load): 14.50 Minute
    • Backup/Run Time With External Battery Cabinet (Half Load): 37.10 Minute
    • Battery Life: 5 Year
    • Hot Swappable: Yes
    • Typical Battery Recharge Time: 6 Hour
    • Replaceable Battery: Yes
    Environmental Conditions
    • Maximum Operating Elevation: 9842.52 ft
    • Storage Temperature: -13°F (-25°C) - 131°F (55°C)
    • Maximum Operating Temperature: 104°F (40°C)
    • Sound Emission: 55 dB
    • Thermal Dissipation: 312.71 W
    Physical Characteristics
    • Product Color: Black
    • Height: 5.2"
    • Width: 17.3"
    • Depth: 26.2"
    • Rack Height: 2U
    • Form Factor:
      • Rack/Tower
      • Rail Mountable
    • Weight (Approximate): 187.39 lb
    Miscellaneous
    • Package Contents:
      • SmartZone U05N11V 5000VA Rack/Tower UPS
      • Intelligent Network Management Card
    • Software Included: SmartZone Cloud Ready
    • Energy Star: Yes
    • Environmentally Friendly: Yes
    • Energy Efficiency Certification: ENERGY STAR 2.0
    • Environmental Compliance:
      • Restriction of Hazardous Substances (RoHS)
      • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    Warranty
    • Limited Warranty: 3 Year
    • Additional Warranty Information:
      • 3 Years for UPS & EBP
      • 2 Years for Battery
