Home » Vertiv Geist Switched Rack PDU with Next Generation IMD - 1U| 30A| 208V| (12) Combination C13/C19 Receptacles| NEMA L6-30P Plug| 4.9kW| VP5N31A1 - VP5N31A1
Vertiv Geist Switched Rack PDU with Next Generation IMD - 1U| 30A| 208V| (12) Combination C13/C19 Receptacles| NEMA L6-30P Plug| 4.9kW| VP5N31A1 - VP5N31A1
Vertiv Geist Switched Rack PDU with Next Generation IMD - 1U| 30A| 208V| (12) Combination C13/C19 Receptacles| NEMA L6-30P Plug| 4.9kW| VP5N31A1 - VP5N31A1

Note: Images and descriptions may not represent actual product accurately. Please confirm all information with Manufacturers.

Vertiv

Vertiv Geist Switched Rack PDU with Next Generation IMD - 1U| 30A| 208V| (12) Combination C13/C19 Receptacles| NEMA L6-30P Plug| 4.9kW| VP5N31A1 - VP5N31A1

1 in stock
SKU: NP5843
$1,384.83
-31% $2,007.00 $1,384.83
For volume or products >$50,000, we can contact the Manufacturer to get even better pricing for you!
For Out of Stock items, please leave a Chat message and we'll get the lead time from the Manufacturer for you.
Click here for Manufacturer Brochure

Vertiv Geist Switched Rack PDU with Next Generation IMD - 1U| 30A| 208V| (12) Combination C13/C19 Receptacles| NEMA L6-30P Plug| 4.9kW| VP5N31A1

  • UPC: 9999999999999
    • General Information
    • Manufacturer: Vertiv
    • Manufacturer Part Number: VP5N31A1
    • Manufacturer Website Address: http://www.vertiv.com/
    • Brand Name: Vertiv Geist
    • Product Line: Geist Upgradeable
    • Product Series: N
    • Product Model: MNS3E1R6-12CF18-3TL6A0H10-S
    • Product Name: GU VP5N31A1 PDU
    • Product Type: PDU
    Technical Information
    • PDU Type: Switched
    • Phase: Single Phase
    • Plug/Connector Type: NEMA L6-30P
    • Plug/Connector Detail: 1 x NEMA L6-30P
    • Receptacle Type: Combination C13/C19
    • Receptacle Detail: 12 x Combination C13/C19
    • Number of Protected Output Receptacles: 12
    • Protection Type: Overcurrent Protection
    • Features:
      • LCD Display
      • Touch Screen Display
    Power Description
    • Input Voltage: 230 V AC
    • Input Voltage Range: 200 V AC - 240 V AC
    • Output Voltage Range: 200 V AC - 240 V AC
    • Power Rating (Watt): 4900 W
    • Input Current: 30 A
    Management
    • Management:
      • DHCP
      • HTTP
      • HTTPS
      • IPv4
      • IPv6
      • LDAP
      • NTP
      • RADIUS
      • RSTP
      • SSH
      • SMTP
      • SNMP (v1/v2c/v3)
      • Syslog
      • TACACS+
    • Remote Outlet Switching: Yes
    Interfaces/Ports
    • Network (RJ-45): Yes
    Physical Characteristics
    • Color Family: Black
    • Product Color: Black
    • Mounting Orientation: Horizontal
    • Mount Type: Rack-mountable
    • Form Factor: Rack
    • Rack Height: 1U
    • Cord Length: 10 ft
    • Height: 1.7"
    • Width: 17"
    • Depth: 12"
    • Weight (Approximate): 12 lb
    Miscellaneous
    • Country of Origin: United States
    • TAA Compliant: Yes
    • Environmentally Friendly: Yes
    • Environmental Compliance: Restriction of Hazardous Substances (RoHS)
    Warranty
    • Limited Warranty: 5 Year
    • Additional Warranty Information:

      5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
